4ms Listen Four Quarters (LFQ) 模組化合成器 - DigiLog 聲響實驗室
Home » Modular Synthesizer » Mixer » 4ms Listen Four Quarters (LFQ) 模組化合成器
4ms  Listen Four Quarters (LFQ) 模組化合成器 - Main Image
4ms  Listen Four Quarters (LFQ) 模組化合成器 - Product Image 1
4ms  Listen Four Quarters (LFQ) 模組化合成器 - Product Image 2

4ms Listen Four Quarters (LFQ) 模組化合成器

Promo Price
NT$  7,290 NT$ 8,050
Earn 72 points with this purchase
Free shipping over NT$3,000
1-year warranty & repair
3/6-month 0% interest
Installment Info:
3 months 0 interest, per month NT$ 2,430
6 months 0 interest, per month NT$ 1,215
預購商品 (約 10~15 個工作天)
NT$ 7,290
 Listen Four Quarters (LFQ) 模組化合成器 4ms Listen Four Quarters (LFQ) 模組化合成器 NT$ 7,290

Listen Four Quarters (LFQ) 模組化合成器

4ms Listen Four Quarters(LFQ)是一台 Eurorack 模組化合成器混音模組,為四聲道立體聲混音器,配備 1/4" (6.35mm) TRS 平衡輸出與 1/8" (3.5mm) 耳機輸出。

The Listen Four Quarters is a four channel stereo mixer with 1/4" (6.35mm) TRS balanced outputs and 1/8" (3.5mm) headphones output. Two mono channels with Pan knobs and two stereo channels with dual inputs provide optimal compatibility with both stereo and mono signals. The Listen Four Quarters can be daisy-chained to other Listen modules to create a larger mixer with sub-mix outputs.

Connect your Listen Four Quarters to other Listen modules or the WAV Recorder using the Audio jumper cable.

產品特色 Basic Features

  • Four input channels (two with stereo inputs, two with mono inputs and a Pan knob)
  • Headphone and main 1/4" outputs, each with separate Level knob
  • Balanced TRS outputs, switchable to stereo
  • Line level output driver with zero impedance, capable of driving long cables
  • Low noise, cross-talk, and bleed-through
  • Anti-pop feature that silences pops and thumps when the power is turned on
  • Headers in back allow for connecting to other Listen Four or Listen Four Quarters modules to create a mixer with 8, 12, 16, or more channels and multiple sub-mix outputs
  • Connects via headers to WAV Recorder module for recording final mix without using patch cables
  • Signal lights for each channel and output mix

隨附配件 Included with the Listen Four Quarters

  • 10-to-16 pin power cable
  • 4 M3 Knurlie screws

商品規格

輸入聲道
4 (2 立體聲 + 2 單聲道含 Pan)
主輸出
1/4" (6.35mm) TRS 平衡,可切換立體聲
耳機輸出
1/8" (3.5mm)
模組寬度
12 HP Eurorack
模組深度
1.13” (28.7mm) 含電源線
電流消耗
+12V: 107mA / -12V: 101mA
最大電流消耗
+12V: 290mA / -12V: 101mA
主輸出頻率響應
+/-0.2dB, 10Hz - 20kHz
最大輸出電平
17.1V peak-to-peak (+17.8dBu)
耳機輸出頻率響應
-0.2dB at 20Hz;0dB at 100Hz to 20kHz (32ohm)
耳機最大電壓
5Vpp
