NT$ 4,500
Home » Audio Interface » USB Type-C Audio Interface » Audient EVO 4 USB 錄音介面 Evo4
體積小又直覺的錄音介面好選擇－Audient EVO 4！
EVO 4 配有非常直覺的使用者介面，可以增強錄音時的效率，捕捉麥克風和樂器動態，將訊號完美的錄製進電腦編輯。 EVO 4 結合了領先的技術性能以及高音質，不管是針對初學者或專業人士，都是非常理想的錄音介面，有了它，除了錄音也可以使用在直播，因為他有非常方便的 Loopback 功能，小小一台，滿足各種錄製需求。EVO 4以 Audient 公司超過 20 年的音訊硬體設計經驗為基礎，可為使用者提供更優質的錄音介面，創造更加無與倫比的音頻質量。
詳細規格
麥克風前級
|
麥克風 Gain 範圍 |
58dB |
|
Line Gain 範圍 |
58dB (-10dB pad) |
|
幻象電源 |
48v +/-4v @ 10mA/Channel |
|
Mic EIN: |
<-128dBu |
|
CMRR: |
>85dB @ 1kHz |
|
最大輸入音量 |
+16dBu |
|
Mic 輸入阻抗 |
>3kΩ Balanced |
|
Line 輸入阻抗 |
>10kΩ Balanced |
|
頻率響應範圍 |
+/-0.5dB 10Hz to 40kHz |
|
串音 |
<-105dBu @ 1kHz & 10kHz |
|
THD+N @ 0dBu (1kHz): |
<0.0015% |
|
SNR: |
100dB |
|
XLR 音訊接孔 |
Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield) |
|
1/4” Jack 音訊接孔 |
TIP (Hot), RING (Cold) & SLEEVE (Shield) |
D.I
|
D.I Gain 範圍 |
58 dB |
|
最大輸入音量 |
+10dBu |
|
輸入阻抗 |
1MegΩ Unbalanced |
|
頻率響應範圍 |
+/-0.5dB 10Hz to 20kHz |
|
THD+N @ 0dBu (1kHz): |
<0.3% |
|
SNR: |
100dB |
|
1/4” Jack 音訊接孔 |
TIP (Hot) & SLEEVE (Shield) |
ADC 輸入
|
數位音量數值 |
0dBFS = +8dBu |
|
頻率響應範圍 |
+/-0.5dB 10Hz to Fs/2 |
|
串音 |
-105dBu @ 1kHz & 10kHz |
|
THD+N @ -1dBFS (1kHz): |
<0.001% |
|
Dynamic Range: |
113dB A-weighted |
DAC 輸出
|
最大輸出音量 |
+11dBu |
|
數位音量數值 |
0dBFS = +11dBu |
|
輸出阻抗 |
<100Ω Balanced |
|
頻率響應範圍 |
+/-0.5dB 10Hz to Fs/2 |
|
串音 |
<-110dBu @ 1kHz |
|
THD+N @ -1dBFS (1kHz): |
<0.0015% |
|
動態範圍 |
113dB A-weighted |
|
1/4” Jack 音訊接孔 |
TIP (Hot), RING (Cold) & SLEEVE (Shield) |
耳機輸出
|
輸出阻抗 |
<50Ω |
|
頻率響應範圍 |
+/-0.5dB 10Hz to Fs/2 |
|
串音 |
-110dBu @ 1kHz |
|
THD+N @ -1dBFS (1kHz): |
<0.0015% |
|
動態範圍 |
113dB A-weighted |
|
最大音量至 30ohms: |
+0.5dBu, 0.0025% THD+N, 1.16Vpk Power: 45mW |
|
最大音量至 60ohms: |
+4.22dBu, 0.0015% THD+N, 1.78Vpk Power: 52mW |
|
最大音量至 600ohms: |
+10.1dBu, 0.0018% THD+N, 3.52Vpk Power: 20mW |
|
1/4” Jack 音訊接孔 |
TIP (Left), RING (Right) & SLEEVE (Shield) |
DSP 混音器迴路延遲（輸入及輸出）
|
44.1 kHz |
0.594ms |
|
48.0 kHz |
0.552ms |
|
88.2 kHz |
0.302ms |
|
96.0 kHz |
0.281ms |
DAW 回放延遲資訊
@ 32 Sample Buffer 樂器回放
|
44.1 kHz |
~2.5ms |
|
96.0 kHz |
~2ms |
DAW 軟體迴路延遲
@ 32 Sample Buffer （輸入及輸出）
|
44.1 kHz |
5ms |
|
96.0 kHz |
4.1ms |
*延遲資訊會因電腦性能而有所不同，音訊的穩定性取決於許多因素，包括 CPU 負載、操作系統和安裝其他驅動程序的性能。
最新 USB 2.0 Type- C 連接
|
No. Of Input Channels |
2 Analogue |
|
No. Of Output Channels |
2 Digital |
|
接頭 |
USB Type-C |
|
內附線材 |
1m USB 2.0 Type-C to USB Type-A |
尺寸相關
|
重量 |
介面本身 |
360g |
|
|
含全配包裝 |
600g |
|
尺寸 |
介面本身 |
140mm (w) x 67mm (h) x 67mm (d) |
|
|
含全配包裝 |
172mm (w) x 88mm (h) x 97.5mm (d) |
