Behringer Model D 合成器音源

Promo Price
NT$  11,900
Earn 119 points with this purchase
Free shipping over NT$3,000
1-year warranty & repair
3/6-month 0% interest
Installment Info:
3 months 0 interest, per month NT$ 3,967
6 months 0 interest, per month NT$ 1,983
預購商品 (約 10~15 個工作天)
NT$ 11,900
Model D 合成器音源 Behringer Model D 合成器音源 NT$ 11,900

純粹的類比電路設計 - Behringer Model D

Behringer Model D 是一款類比合成器音源(不含鍵盤),帶有 3 個 VCO、Ladder Filter、LFO 的傳奇合成器設計,並兼容模組化合成器 Eurorack 規格,可拆下主體並放置在 Eurorack 中。

Behringer Model D 官方介紹影片
此影片中不僅介紹 Model D 基本功能,也透過連結其他 Behringer 合成器以創造更多聲音的可能性

產品特色

  • 帶有三個 VCO 的經典設計,可做出相當肥厚的類比合成器聲響
  • 採用原始的「D Type」電路和 transistors 和 JFETs 設計
  • 純正的類比訊號皆奠基於原始的 VCO、VCF、VCA 設計
  • 5 個可調整的 oscillator 波型、以及可調整的 pulse widths 可做出完美音色
  • 經典的 24 dB ladder filter 傳奇聲音
  • 可切換的 low/high pass filter 模式讓聲音更多樣化
  • 全類比的三角波/方波 LFO
  • 16 發聲數的 Poly Chain 可以串接多台,最多到 16 個複音發聲
  • 半模組的設計,不需任何接線就能開始演奏
  • 內建破音,可使聲音更加突出
  • Noise generator 更大幅增加了 waveform 可能性
  • 總共有 48 個可控制選項、可以即時改變音色
  • External audio input 可以處理外部音訊
  • 廣泛的 MIDI channel 設定

商品規格

類型
類比合成器音源(不含鍵盤)
發聲數
單發聲 (Mono)
Oscillators
3 x VCO
Filter
24dB Ladder Filter, low-pass/high-pass
類比輸入
1 x 3.5 mm
類比輸出
2 x 6.3 mm、3 x 3.5 mm(含耳機監聽)
MIDI I/O
In / Thru / USB
USB
1 x Type B
電源供應
12V DC(內含)
模組寬度
70 HP(相容 Eurorack)
尺寸
高 8.89 cm x 寬 37.5 cm x 深 13.8 cm
波形 (Waveforms)
Triangle, Sawtooth, Tri-sawtooth, Square, Wide Pulse, Narrow Pulse, Reverse Sawtooth (osc 3)
展開完整規格(4 項)
雜訊產生器 (Noise Generator)
White, Pink
包絡產生器 (Envelope Generator)
2 x EG (attack, decay, sustain)
LFO
Triangle, Square wave
效果類型
Overdrive circuit
