Kenton USB Solo Converter

產品特色

由於直接由 USB 連接和供電，USB Solo 可以滿足從電腦上控制模擬合成器的需求。不需要MIDI接口，也不需要外部電源，因此線材的混亂程度降到了最低。但 USB Solo 仍然保持著 Kenton 著名的 tuning 穩定性，以及由於內部電路，CV 和輔助輸出的全刻度範圍。

CV 輸出可以在 1V/Oct 、Hz/Volt 或 1.2V/Oct 下運行。scaling 和 tuning 都可以調整，用以搭配任何類型的合成器。Gate Output 可以在幾個不同的電壓下使用，也可以設置為 S-trig 使用。此外，USB Solo 還有一個 Sync24 輸出，所以舊款的 Roland 設備同樣也可以使用。

Kenton USB Solo Converter 是一個符合等級標準的 USB MIDI 轉換器，不需要安裝任何驅動程序，即插即用。

詳細規格

• 電源: Power is supplied by the USB host device via the USB cable
• 尺寸: 130 x 97 x 40 mm
• 重量: 450g
• MIDI: In & Out (via USB)
• Analog Outputs: CV on 3.5mm mono jack (V/oct or Hz/V or 1.2V/oct)
• Gate on 3.5mm mono jack (Gate or S-trig – with or without pullups)
• Aux1 on 3.5mm mono jack (CV and Aux 1 use 16bit DAC for rock steady pitches)
• Digital Outputs Aux2 & Aux3 on 3.5mm mono jacks (off=0 volts on=+5 volts)
• Sync 24 on 5 pin 180 degree DIN socket
• USB Connector Type B socket – USB A to B cable supplied 1.8 metre
• Please refer to the manual for more details
• Designed to control all types of mono-synth
• Super-fast response time
• Famous Kenton build quality
• Rugged brushed aluminium case
• CV and Aux1 outputs use high specification 16 bit D/A converters for rock-steady pitches
• Gate / S-trig output configurable output to match virtually any synth
• Aux2 & Aux3 outputs are on-off only (zero or 5V)
• Dedicated DIN socket output for Sync24
• CV/Gate/Aux1,2,3 outputs on 3.5mm jack sockets (3.5mm to 1/4″ cables are available in our cables section)
• Any MIDI channel can be selected
• Switchable for V/oct & Hz/V & 1.2V/oct scaling systems
• Fine tune & scale are software controllable
• Transpose (coarse tune) – up & down 12 semitones
• Adjustable pitchbend range
• Programmable Gate V-trig (up to 15v) or S-trig (with or without pull-up)
• Multiple and single trigger modes – adjustable re-trigger time
• Note priority selection – newest / lowest / highest
• Old notes are remembered to facilitate trill effects and increase playability
• Portamento – fixed rate or fixed time modes
• Auto Portamento mode selectable (where legato playing turns on Portamento)
• Portamento Controller is selectable
• Programmable Auxilary outputs controllable by any MIDI controller
• Programmable LFO – 9 wave shapes inc. random
• LFO can modulate pitch &/or AUX output
• Separate Controllers for LFO to CV and LFO to AUX
• LFO can be synchronised to MIDI clock
• LFO sync point can be selected
• Key-on can reset LFO
• Aux3 output can output clock – Aux2 can output stop-start
• Clock output can select from 1 to 12, 24, or 48 clocks per quarter note
• All parameters are controllable in real-time by SysEx
• Set-ups are stored in non-volatile memory for easy recall
• 40 memory locations for store / load
• MIDI monitor mode – for easy MIDI troubleshooting
• USB powered
• Size 130mm x 97mm x 40mm
• Suitable for use with XP / Vista / MAC OS-X v10.2 onwards / Linux
• Improvements over Pro-Solo mkII
• USB connection – faster data transfer
• Has 40 memories which can be stored and recalled
• Setups pre-loaded for popular synths
• Dedicated DIN Sync-24 output
• Aux 2 & 3 on 3.5mm jacks
• Variable gate-off time for re-trigger (multiple trigger)
• LFO start point can now be selected for Sample & Hold too
• Aux 2 & 3 have adjustable threshold
• Program changes can be used to recall memories
