Kenton Pro 2000 MK2

產品敘述

為了用 MIDI 樂器或音序器控制 MIDI 合成器，需要把數位 MIDI 訊號轉換成 MIDI 合成器能夠理解的信號。

對於這個價格來說，可能就是市場上性價比最高的 MIDI 訊號轉換器。

擁有的眾多功能，讓 Pro 2000 MK2 具有非常優秀的泛用性。

詳細規格

• Power: 230v AC 50Hz (170v – 260v) or 115v AC 50/60Hz (85v – 130v).
• 尺寸 : 280mm x 132mm x 42mm
• 重量 : 2.5Kg
• MIDI: In Out and Thru
• Outputs: CV on 3.5mm jack (V/oct or Hz/V)
• Gate on 3.5mm jack (Gate or S-trig)
• Aux on 3.5 mm jack
• 15 pin High Density D or 8 pin Mini Din (with optional expansion port)
• Options: DCB port with cable, KADI/WASP port with cable
• Design for all type of mono-synth
• Super-fast response time
• Famous Kenton build quality
• Rugged steel case
• Main CV outputs have high specification 16 bit D/A converters for rock-steady pitches
• Auxiliary outputs have 12 bit D/A converters
• Mains powered – internally selectable 230/115 volts (IEC socket on back panel)
• Units are shipped pre-set to the correct voltage for your country
• 16×2 Character LCD display
• 24 memory locations for setups
• MIDI IN socket
• MIDI OUT socket (for MIDI channel filter and SysEx dumps)
• MIDI THRU socket
• DIN SYNC 24 socket
• Clock output with selectable 1 to 12 cpqn plus 24 and 48 cpqn modes
• Any MIDI channel can be selected for any output
• Two COMPLETELY INDEPENDENT main CV outputs (this means ALL settings for synth outputs A & B)
• Main CV outputs A & B are independently switchable for V/oct & Hz/V & 1.2V/oct scaling systems
• Fine tune & scale are software controllable
• Transpose (coarse tune) – up & down 12 semitones
• Adjustable pitchbend range +/- 12 semitones
• Programmable Gate V-trig (up to 15v) or S-trig (with or without pull-up)
• Multiple and single trigger modes
• Note priority selection – newest / lowest / highest
• Old notes are remembered to facilitate trill effects and increase playability
• Portamento on main CV outputs
• Auto Portamento mode selectable on main CVs (where legato playing turns on Portamento)
• Two different types of Portamento are selectable (fixed rate / fixed time)
• Portamento Controllers are selectable
• 6 Programmable Auxilary outputs controllable by any MIDI controller on any MIDI channel
• 2 Programmable and independent LFOs – each with 9 wave shapes including random
• LFO can modulate pitch &/or AUX outputs
• Separate Controllers for LFO to CV and LFO to AUXes
• LFOs can be synchronised to MIDI clock
• Channel filter to ‘channelise’ an ‘omni-on’ synth
• Polyphonic operation selectable with 3 note assignment types
• All parameters are controllable in real-time by SysEx
• SysEx dump and load of current program and any memory
• Set-up are stored in non-volatile memory for easy recall
• MIDI monitor mode – for easy MIDI troubleshooting
• Optional add-on port for KADI on its own MIDI channel
