Description

The latest in our popular Pro Solo line of converters, the Pro Solo mk3 features a number of improvements over its predecessor; including 3 continuously variable auxiliary outputs, a built-in ADSR envelope generator, the ability to smooth out steppy MIDI CCs and more.

The Pro Solo mk3 is highly configurable and is the ideal converter for anyone looking to incorporate an analogue synthesizer, vintage or otherwise, into their MIDI setup. The CV output can operate at 1V/Oct, Hz/Volt or 1.2V/Oct. The scaling and tuning are adjustable, to accommodate any unruly synths. The Gate output can work at several different voltage levels, and can also be set to work a S-trig instead.

The three continuously variable auxiliary outputs are presented on 3.5mm jack sockets; and can be configured to respond to MIDI CCs, velocity, aftertouch, clock and more. In addition to this, the MIDI OUT port can be switched to output Sync24, so your vintage Roland equipment can join in as well.

All leads are sold separately as we do not know what you want to connect to.


Features

Power: 9V DC (regulated or unregulated) – never apply more than 12V(never use an unregulated supply greater than 9V as unregulated supplies typically give a higher output than shown). 9V switch mode power supply included. Products bought directly from Kenton are supplied with the appropriate power supply for the delivery address. Four types are available, UK / EU / USA / Australia.
Dimensions: 140 x 87 x 45 mm
Weight: 210g
MIDI: In, Thru (selectable)
Analogue Outputs: CV on 3.5mm jack (V/oct or Hz/V)
Gate on 3.5mm jack (Gate or S-trig)
Aux 1, 2 & 3 on 3.5 mm jack
Sync 24 Output: MIDI Thru socket switchable to work as Sync 24 output instead, with variable CPQN ratio

Please refer to the manual for more details

Designed to control all types of mono-synth
Super-fast response time
Famous Kenton build quality
Rugged brushed aluminium case
CV output uses high specification 16 bit D/A converter for rock-steady pitches
Runs from standard 9 volt power supply, 2.1mm centre positive
CV/Gate/Aux outputs on 3.5mm jack sockets (3.5mm to 1/4″ cables are available in our cables section)
MIDI IN socket
MIDI THRU socket can be switched to become Sync 24
Any MIDI channel can be selected
Switchable for V/oct & Hz/V & 1.2V/oct scaling systems
Fine tune & scale are controllable using the edit buttons & settings can be stored
Transpose (coarse tune) – up & down 12 semitones
Adjustable pitchbend range
Programmable Gate V-trig (up to 15v) or S-trig (with or without pull-up)
Multiple and single trigger modes
Note priority selection – newest / lowest / highest
Old notes are remembered to facilitate trill effects and increase playability
Portamento – fixed rate or fixed time modes
Auto Portamento mode selectable (where legato playing turns on Portamento)
Portamento Controller is selectable
Three programmable Aux variable analogue outputs, controllable by any MIDI controller
Programmable LFO – 9 wave shapes inc. random
LFO can modulate pitch &/or Aux 1 output
Separate Controllers for LFO to CV and LFO to Aux 1
LFO can be synchronised to MIDI clock
LFO sync point can be selected
Key-on can reset LFO
Aux outputs can output clock, with two individual dividers to choose from
All parameters are controllable in real-time by SysEx
32 setups can be stored in non-volatile memory for easy recall
MIDI Analyser mode – for easy MIDI troubleshooting
Power supply included – UK / EU / USA / Australian types available

What’s new or different about the Mk3?

Aux 2 & Aux 3 are now continuously variable analogue outputs and are presented on 3.5mm jack sockets
Expanded selection of Controllers available for the Aux outputs
The Aux outputs now have adjustable slew rate (rise/fall time) to enable you to smooth out any controller jumps
Built-in ADSR envelope generator (the controls for which can be assigned to MIDI CCs)
Drum Trigger mode – Aux outputs can be set to produce a velocity-variable trigger pulse for drum synths, each with its own dedicated trigger note
Dual clock dividers, which can be used simultaneously on different outputs, including the DIN socket when not used as MIDI out
Variable gate-off time for re-trigger (multiple trigger)
32 program memories which can store and recall setups
MIDI Program Changes can be used to recall setups
Pre-loaded setups for many of the most popular synths
Pitchbend range increased to 48 notes up & down
Flash upgradable using SysEx when updates become available
32 bit ARM processor
Brushed aluminium case with black text
