Kenton Pro Solo MK3 | DigiLog 聲響實驗室
買器材 » MIDI 器材 » MIDI 轉換介面 » Kenton Pro Solo MK3
Pro solo
Pro solo

Kenton Pro Solo MK3

滿 NT$ 3,000 全台免運費

促銷價 NT$ 7,500

分期資訊:
30 利率,每期 NT$ 2,500
60 利率,每期 NT$ 1,250

商品狀態:預購商品 (約 10~15 個工作天)

保固資訊:1 年保固 (不包含: 配件、線材、modular)
滿 NT$ 3,000 全台免運費
付款方式: 7 11 Family mart Hilife Ok Visa Jcb Atm Cash delivery
加入慾望清單
已加入慾望清單

Watched 此商品被關注 4937 次

產品特色

Pro Solo mk3 是 Kenton Pro Solo 系列的最新產品,與上一代產品有許多不同;包括3個連續可變的輔助輸出,一個內置的 ADSR envelope generator,MIDI CCs 等等。

Pro Solo mk3 具有高度的可配置性,對於希望將模擬合成器(不管是機型相對老舊的還是其他類型的)納入 MIDI 配置的用戶來說,是一台理想的轉換器。 CV 輸出可以在 1V/Oct、Hz/Volt 或 1.2V/Oct 下運行。Scaling 和 Tuning 都可以調整,以適應多種類型的合成器。Gate 輸出能夠在一些不同電壓的情況下使用,也可以設置為 S-trig 使用。

三個連續可變的輔助輸出在 3.5mm 上,可以配置為響應 MIDI CCs、velocity、aftertouch、clock 等等。除此之外,MIDI OUT 端口可以切換到輸出 Sync24 ,舊款的 Roland 設備也能使用。



詳細規格

  • 電源 : 9V DC (regulated or unregulated) – never apply more than 12V(never use an unregulated supply greater than 9V as unregulated supplies typically give a higher output than shown). 9V switch mode power supply included.
  • 尺寸 : 140 x 87 x 45 mm
  • 重量 : 210g
  • MIDI: In, Thru (selectable)
  • Analogue Outputs: CV on 3.5mm jack (V/oct or Hz/V)
  • Gate on 3.5mm jack (Gate or S-trig)
  • Aux 1, 2 & 3 on 3.5 mm jack
  • Sync 24 Output: MIDI Thru socket switchable to work as Sync 24 output instead, with variable CPQN ratio
  • Please refer to the manual for more details
  • Designed to control all types of mono-synth
  • Super-fast response time
  • Famous Kenton build quality
  • Rugged brushed aluminium case
  • CV output uses high specification 16 bit D/A converter for rock-steady pitches
  • Runs from standard 9 volt power supply, 2.1mm centre positive
  • CV/Gate/Aux outputs on 3.5mm jack sockets (3.5mm to 1/4″ cables are available in our cables section)
  • MIDI IN socket
  • MIDI THRU socket can be switched to become Sync 24
  • Any MIDI channel can be selected
  • Switchable for V/oct & Hz/V & 1.2V/oct scaling systems
  • Fine tune & scale are controllable using the edit buttons & settings can be stored
  • Transpose (coarse tune) – up & down 12 semitones
  • Adjustable pitchbend range
  • Programmable Gate V-trig (up to 15v) or S-trig (with or without pull-up)
  • Multiple and single trigger modes
  • Note priority selection – newest / lowest / highest
  • Old notes are remembered to facilitate trill effects and increase playability
  • Portamento – fixed rate or fixed time modes
  • Auto Portamento mode selectable (where legato playing turns on Portamento)
  • Portamento Controller is selectable
  • Three programmable Aux variable analogue outputs, controllable by any MIDI controller
  • Programmable LFO – 9 wave shapes inc. random
  • LFO can modulate pitch &/or Aux 1 output
  • Separate Controllers for LFO to CV and LFO to Aux 1
  • LFO can be synchronised to MIDI clock
  • LFO sync point can be selected
  • Key-on can reset LFO
  • Aux outputs can output clock, with two individual dividers to choose from
  • All parameters are controllable in real-time by SysEx
  • 32 setups can be stored in non-volatile memory for easy recall
  • MIDI Analyser mode – for easy MIDI troubleshooting
  • Power supply included – UK / EU / USA / Australian types available

What’s new or different about the Mk3?

  • Aux 2 & Aux 3 are now continuously variable analogue outputs and are presented on 3.5mm jack sockets
  • Expanded selection of Controllers available for the Aux outputs
  • The Aux outputs now have adjustable slew rate (rise/fall time) to enable you to smooth out any controller jumps
  • Built-in ADSR envelope generator (the controls for which can be assigned to MIDI CCs)
  • Drum Trigger mode – Aux outputs can be set to produce a velocity-variable trigger pulse for drum synths, each with its own dedicated trigger note
  • Dual clock dividers, which can be used simultaneously on different outputs, including the DIN socket when not used as MIDI out
  • Variable gate-off time for re-trigger (multiple trigger)
  • 32 program memories which can store and recall setups
  • MIDI Program Changes can be used to recall setups
  • Pre-loaded setups for many of the most popular synths
  • Pitchbend range increased to 48 notes up & down
  • Flash upgradable using SysEx when updates become available
  • 32 bit ARM processor
  • Brushed aluminium case with black text
