詳細規格

Frequency Response

48 Hz - 20 kHz (± 2 dB)

Low cutoff -6dB
41 Hz

High cutoff -6dB
21 kHz

SPL

Peak SPL
≥115 dB

Maximum peak acoustic output per pair at 1 m distance with music material.

Short term max SPL
≥105 dB

Maximum short term sine wave acoustic output on axis in half space, averaged from 100 Hz to 3 kHz at 1 m.

Long term max SPL
≥99 dB

Maximum long term RMS acoustic output in same conditions with IEC weighted noise (limited by driver unit protection circuit) at 1 m.

Self-generated noise

Self-generated noise
≤10 dB

Self generated noise level in free field at 1m on axis (A-weighted).

Weight

Weight
9.4 kg (20.7 lb)

Dimensions

Height
350 mm (13 25/32 in)

Height with Iso-Pod™
365 mm (14 3/8 in)

Width
237 mm (9 21/64 in)

Depth
223 mm (8 25/32 in)

Enclosure

Enclosure Material
Die cast aluminium

Enclosure Type
Reflex port

Drivers

Bass


Driver Type
Cone

Magnetically shielded

Diameter
165 mm (6 1/2 in)

Treble


Driver Type
Metal dome

Magnetically shielded

Diameter
19 mm (3/4 in)

Directivity

Horizontal Directivity

Harmonic Distortion

50…100 Hz ≤2 dB
> 100 Hz ≤0.5 dB

Amplifier Section

Amplifiers

8040B bass amplifier

90 W Class AB

8040B treble amplifier

90 W Class AB

Mains Voltage

100, 120, 220 or 230VAC 50/60Hz according to region

Power consumption

ISS active
≤0.5 W

Idle
≤10 W

Full output
110 W
