Erica Synths Black Hole DSP MK1

Erica Synths Black Hole DSP by default has 16 effects, each with 4 adjustable and CV controllable parameters and CV controlled effect select.

Features

Spin FV-1 chip
16 unique custom effects
Stereo INs and OUTs
3 manually and CV controllable parameters
CV controlled effect select
Manually and CV controllable clock rate reduction for noisy bitcrush
7 segment display for effect select indication
Audio clipping LED
Exchangeable external effect boards

This module tops the Erica Black series with mind blowing sound effects that are designed in a close co-operation of Erica Synths team rider KODEK and Spin CAD software creator Gary Worsham. Furthermore, external effect boards (sold seperately) containing sets of effects can adapt Erica Black Hole DSP to your way of creating music. Use the module with Erica Black CV Expander for more delicate CV control over parameters.

Erica Black series are high-end modules with unique functionality. Only the highest quality components are used and all inputs and outputs are protected against undesired overvoltage. When designing the Black Series, we did not economise on the module width, we put design and usability first. Big knobs are assigned to functions that make difference in sound. Together the Erica Black series are a range of modules that make an entire synthesizer.

Technical specifications:

Audio input level	up to 20V ptp
CV input level	-10V - +10V
Signal attenuation	-80dB
Panel width	14HP
Module depth	35mm
Power supply	21mA@+12V, 32mA@-12V
