Tiptop Audio Z4000 VC - EG

Promo Price
NT$  5,250
Earn 52 points with this purchase
Free shipping over NT$3,000
1-year warranty & repair
3/6-month 0% interest
Installment Info:
3 months 0 interest, per month NT$ 1,750
6 months 0 interest, per month NT$ 875
預購商品 (約 10~15 個工作天)
NT$ 5,250
Z4000 VC - EG Tiptop Audio Z4000 VC - EG NT$ 5,250

Z4000 — Voltage Controlled Envelope Generator

Tiptop Audio Z4000 是一款電壓控制(Voltage Controlled)的類比包絡產生器(Envelope Generator),產生由 Attack、Decay、Sustain、Release 四個經典段落組成的包絡,每一段都可手動以旋鈕設定,或在電壓控制下動態調變。

The Z4000 NS is a snappy voltage-controlled analog envelope generator with a built-in CV processor for scaling, inverting, and voltage-controlled deviating of the envelope shape. The Z4000 generates an envelope made of the four classic segments: Attack, Decay, Sustain and Release, in which each segment can be manually set using knobs or dynamically set under voltage control.

Control knobs for the Attack, Decay, and Release segments are scaled. The first 0-50% of the knobs rotation is dedicated to high resolution adjustment in the millisecond range.

The output levels are fully adjustable with signals that can reach up to 10V in either polarity and can be mirrored into the opposite polarity or clipped using the voltage-controlled deviater-scaler. A bi-color LED indicates intermediate values in both polarities and their crossfade state.

The Attack slope switch allows selection of a logarithmic or exponential curve for the Attack segment. This subtle effect helps further the fine adjustment of the Attack segment slope. A Shoot button is provided to let you fire the envelope manually. The Z4000 also provides a retrigger input allowing you to create legato notes when using a classic keyboard interface.

Going down to nuts and bolts, the Z4000’s smoothness and snappiness is made possible by a four segment active-charge discrete circuit which is an extended version of circuits found in classic two segment rise / fall transient generators.

商品規格

模組類型
Voltage Controlled Envelope Generator
包絡段
Attack, Decay, Sustain, Release
輸出電壓
up to 10V(雙極性)
模組寬度
8HP
深度
28mm
電流消耗
+12V 34ma / -12V 18ma
