Erica Synths Black 3109 VCF/VCA 模組

Promo Price
NT$  7,000
Earn 70 points with this purchase
Free shipping over NT$3,000
1-year warranty & repair
3/6-month 0% interest
Installment Info:
3 months 0 interest, per month NT$ 2,333
6 months 0 interest, per month NT$ 1,167
預購商品 (約 10~15 個工作天)
NT$ 7,000
Black 3109 VCF/VCA 模組 Erica Synths Black 3109 VCF/VCA 模組 NT$ 7,000

Black 3109 VCF/VCA - Roland 經典 IR3109 晶片音色重現低通濾波器 + VCA 模組

Erica Synths Black 系列以 AS3109 VCF 積體電路為核心的低通濾波器與電壓控制放大器(VCA)二合一模組。AS3109 是傳奇 Roland IR3109 晶片的現代復刻版本,IR3109 正是 Jupiter 系列、Juno 系列與 SH-101 等 Roland 經典合成器的濾波器核心,造就了那個世代無可取代的溫暖低通音色。Black 3109 VCF/VCA 在忠實重現 IR3109 音色特質的基礎上進一步改良:加入共鳴音量補償電路(消除原版晶片在高共鳴時音量下降的缺陷)、整合獨立 VCA(一模組取代兩模組)、以及 1V/Oct 音高追蹤(濾波器鍵盤追蹤精準,甚至可作為 VCO 使用)。





產品特色

AS3109 晶片 — Roland 經典音色核心

・採用 AS3109 VCF 積體電路,為 Roland IR3109 晶片的現代版本

・IR3109 原搭載於 Roland Jupiter-4、Jupiter-6、Juno-60、Juno-106、SH-101 等傳奇型號

・重現這些合成器標誌性的溫暖、圓潤低通音色,對原始電路音色高度還原



原版缺陷改良

・加入共鳴音量補償電路:原版 IR3109 設計在共鳴提升時會產生明顯音量下降,此問題已於本模組完全解決

・整合獨立 VCA:省去外接 VCA 模組的需求,單一 10HP 面板涵蓋濾波與音量控制兩大功能



1V/Oct 追蹤與雙用途設計

・Cutoff 支援 1V/Oct 音高追蹤,可配合鍵盤或音序器進行精準濾波掃描

・1V/Oct 追蹤精度足夠時,本模組亦可作為 VCO 使用,大幅提升創作靈活性



CV 控制

・Cutoff 截止頻率 CV 輸入:-5V – +5V(全掃範圍)

・VCA 電壓控制輸入:0 – +10V

・適合搭配包絡器與 LFO 進行動態濾波與音量調制



詳細規格

訊號規格

・音頻輸入電平:10 Vptp

・Cutoff CV 輸入電壓(全掃範圍):-5V – +5V

・VCA CV 輸入電壓:0 – +10V

・濾波器類型:低通(Lowpass)

・1V/Oct 追蹤輸入:支援



模組規格

・面板寬度:10 HP

・模組深度:35 mm

・電源消耗:25 mA @+12V,25 mA @-12V



Line 好友

保固說明

關於 DigiLog

加入好友

Reviews:

目前尚無評論

Purchase FAQ

Q1. How is shipping calculated? Is there free shipping?

Orders over NT$3,000 qualify for free shipping. Orders under NT$3,000 incur a NT$120 shipping fee. In-store pickup is always free.


Q2. What payment methods are available?

We accept: credit card (single payment, or 3/6-month installments), bank transfer, convenience store payment code, cash on delivery, in-store payment, and AFTEE deferred payment. Installments are currently available only for credit cards issued by CTBC Bank, E.SUN Bank, and Taishin Bank. Cash on delivery is not available for software products or orders over NT$10,000.

E-invoices are issued for all purchases and sent automatically to your registered email. Once a personal (duplicate) invoice is issued, it cannot be changed or reissued as a company (triplicate) invoice.


Q3. How does in-store pickup work?

Select "In-store pickup" (free) at checkout. We will notify you by email once your items are ready. Please bring your order information to the store.

Store address: 2F., No. 2-1, Aly. 2, Ln. 244, Sec. 3, Roosevelt Rd., Zhongzheng Dist., Taipei City. Opening hours: Monday to Saturday 11:00 – 18:30 (closed on Sundays).


Q4. What is the inspection period?

According to the Consumer Protection Act, online purchases come with a 7-day inspection period starting from the delivery date. Please note that the "inspection period is not a trial period." The purpose is for you to inspect and review the product, not to use it. If you are unsatisfied after inspection, please do not open or use the product and follow the return procedures immediately. Returned products must be in complete packaging with all accessories, gifts, and original packaging intact. Any missing, damaged, or incomplete items may affect your return rights and restoration costs may be deducted.


Q5. How do I process a return or exchange?

If you wish to return a product, please ensure it is in complete, new condition with the original packaging undamaged. This includes the product itself, accessories, warranty card, original packaging, and all accompanying documents. If the product is damaged due to reasons attributable to you, we may not be able to process the return, or repair costs may be deducted from the refund. However, products with manufacturing defects are exempt and qualify for unconditional return or exchange.

Please contact us by phone or email within the inspection period, providing the reason for the return/exchange, current product condition, phone number, and pickup address. We will arrange the return within 3-5 business days.


Q6. How will I receive my refund, and how long does it take?

Refund methods and timelines vary by payment method:

Credit Card: After we receive the returned product, the refund will be credited to your credit card account within approximately 5-7 business days. Depending on your billing cycle, the refund may appear on your current or next statement. Please confirm with your credit card issuing bank.

Bank Transfer: Please contact service [at] digilog.tw with your complete bank details (bank name, branch name, bank code, account holder name, account number). We will arrange courier pickup of the returned product and transfer the refund to your designated account within 5-7 business days.


Q7. Is there a warranty on products?

Products come with a 1-year warranty. For repairs during the warranty period, please contact service [at] digilog.tw or call +886-2-23638171.


Q8. Do I need to pay for shipping when sending products for repair?

Round-trip shipping costs for product repairs are the customer's responsibility.

Erica Synths Others:

Erica Synths Pico VCO 震盪器模組 - VCO
Erica Synths Drum Modulator - LFO
Erica Synths Pico Mixer 混音器模組 - Mixer
