MEMS Mic 在 2HP 的面板寬度裡放進一顆 MEMS 全指向麥克風,直接把人聲、樂器、環境音——或是你刻意製造的回授——變成 Eurorack 系統可以處理的音訊訊號。
MEMS(Micro-Electro-Mechanical System)麥克風是把微機電元件直接做在電路板上、再加一層機械外殼保護,手機、平板、相機裡用的都是這種。體積極小,但在 6Hz 到 20kHz 的範圍內頻率響應相當平坦,用在音樂場合表現意外地好。
輸出音量可以用面板推桿控制,也可以吃 CV——接上 CV 之後推桿自動變成衰減器,等於多了一路可調變的增益。面板上有兩顆指示燈,綠燈顯示有訊號、紅燈顯示過載。另外有一個固定的低頻衰減開關(180Hz,6dB/oct),處理近距離收音的低頻堆積很有用。想做立體聲的話,掛兩片各自調變就可以。
