Home » Modular Synthesizer » VCO » Gamechanger Audio Plasma Voice
採用 High-Voltage Electrical Discharge (HVED) 技術的合成器 - Gamechanger Audio Plasma Voice
Plasma Voice 大概是少數幾顆採用 HVED 元件來發聲的 Eurorack 模組，從下方介紹影片中就可以聽出其與一般 Oscillator 有什麼不同。
Plasma Voice 如何運作？
PLASMA Voice 是一個合成器模組，通過操縱一個特別設計的氙氣填充氣體管上的兩個電極之間的高電壓反應來發聲。 這些電擊通過專用的整流器電路轉換為類比聲響，能夠發出一種迷人的電氣聲音，與藍色電流的視覺效果相匹配。 這些電擊由一個專有的 Ultrasound Pulse-Width Oscillator 驅動。
這個振盪器被預設好的 Envelope Shape（或者為了簡單起見，可以直接稱之為聲音）Modulation，你可以選擇、觸發、塑造和使用 Fader 和 CV 輸入來調變。
體驗全新的聲音可能性
該模組具有可選的「聲音」，這些聲音被組織成不同的「Bank」，每個 Bank 都專門用於特定的聲音：
1. Bass 2. Lead 3. Pluck 4. Drum 5, Metal 6. Static 7. Spark
Fader 允許修改每個「聲音」，能夠將其轉變為超出 Bank 預期定義的樣貌。你可以盡情探索這些美妙而奇異的聲音可能性。
完全獨立的 PLASMA Voice
PLASMA Voice 是我們 PLASMA 系列的最新成員。雖然它採用相同的技術，但以前的產品是專門用於 Distortion 效果。大部分聲音塑造參數都被設置在最佳的 Sweetspot，以確保穩定的失真，而這次 GameChanger 充分利用 HVED 元件的潛力，創造了第一個不需要外部聲源的 PLASMA 產品。它是一個完全獨立的聲音模組。
產品特色
聲音引擎部分
- 採用 HVED 引擎
- 7 BANKS 中包含 49 種可變化的聲音
- 由複雜的數位合成引擎驅動，並以 Pulse-Width / Frequency Modulation / Sample Pitch Modulation / Envelope time stretch / Wavefold / Crossmod / Suboctave Modulation 加以調變
Analog Signal Path
- Soft clipping DRIVE 破音電路
- BASS and TREBLE EQ 可以 Boost / Cut
- 類比濾波器電路，12dB/Oct LP 或 HP，配有 Resonance 可調
- 類比輸出的 VCA
- VCF 以及 VCA 皆可用 CV 訊號控制
- Audio 輸出可調：+/-8V Max
控制項
- 6 個 Fader
- PITCH +/- 1 oct (fine tune and octave settings are also available)
- TIME – envelope time stretch
- MOD – pitch modulation effect
- HARM – harmonic content effect
- FLUX – electric artefact effect
- FILTER – cutoff with and without envelope modulation
- 5 個 CV 輸入，用於 Attenuverter
- 手動的 TRIGGER / GATE 按鈕
- CLUTCH 按鈕，用於暫時性的參數編輯
- Push & turn ENCODER 以及 7:7 LED 指示燈，用於標示選擇的 SOUND & BANK 以及其他操作項
CV&Trigger
- 7 個 CV 輸入：6 個 SLIDE 選擇、以及 1 個可以 Assign 的 CV 控制項
- Pitch CV 1V/Oct, +/-10V range
- Parameter CV, +/-5V range
- TRIGGER and ACCENT inputs: 2V minimum, rising and falling edge detect.
- 5 TRIGGER input modes: TRIG, GATE, LOOP, OSC, ON/OFF
- 7 ACCENT modes: ACC, DUCK, STARVE, CVFREEZE, JUMP, REVERSE, BURST
設定選項
- 5 TRIGGER modes
(TRIG, GATE, LOOP, OSCILLATE, ON/OFF) - 7 ACCENT modes
(ACENT, DUCK, STARVE, CV FREEZE, PITCH JUMP, REVERSE, BURST) - MULTICV assignment
- MIDI channel select
- Center pitch select
- Master octave offset
- FILTER mode select
- Auto save of all settings
MIDI
- 3.5mm MIDI IN，內含一個 3.5mm 轉 5-Pin MIDI 的轉接頭
- MIDI support: Notes, Velocity, CC panel control, PC BANK & SOUND change, PC settings change, Channel 10 General Percussion Key Map, Pitchwheel, Modwheel
- 可以透過 MIDI SysEx 更新 Firmware
詳細規格
- Voltage: +/-12V DC，內附排線，可以直接接上 Eurorack 電源箱
- 電流：Peak 220mA at +12V (mean 75mA), 35mA at -12V. 0 at +5V
- 寬度：16HP (W x H: 81.3 x 128.5mm)
- 深度：35mm excl. knobs, 54mm incl. knobs
- 淨重：190g
