MIPRO ACT-5814A ACT-580H*4 無線麥克風系統

Promo Price
NT$  33,000
Earn 330 points with this purchase
Free shipping over NT$3,000
1-year warranty & repair
3/6-month 0% interest
Installment Info:
3 months 0 interest, per month NT$ 11,000
6 months 0 interest, per month NT$ 5,500
預購商品 (約 10~15 個工作天)
NT$ 33,000
ACT-5814A ACT-580H*4 無線麥克風系統 MIPRO ACT-5814A ACT-580H*4 無線麥克風系統 NT$ 33,000

MIPRO ACT-5814A 5 GHz 數位四頻道無線麥克風系統|避開 Wi-Fi 與 UHF 干擾、1.5 ms 超低延遲、48 kHz/24-bit,ACT-580H 手握麥克風 ×4

MIPRO ACT-5814A 是一套 5.8 GHz 數位四頻道無線麥克風系統,由全機架寬(19 吋)金屬機箱的 ACT-5814A 四頻道數位接收機,搭配四支 ACT-580H 數位手握式無線麥克風組成。一台 1U 接收機同時接收四支麥克風,採用 ISM 5 GHz 頻段避開 UHF、2.4 GHz 無線產品與 Wi-Fi 的干擾;48 kHz/24-bit 數位取樣、動態範圍逾 120 dBA、B 群組傳輸延遲低於 1.5 ms,適合會議中心、座談會與多空間配置的商用場域。

頻率規劃分 A、B 雙群組共 24 組頻道(A 群組 12 組、B1/B2 各 12 組),每頻道再有 64 組 ID 與 1 組特殊 ID,多間會議室同時使用也不互相干擾;Channel Scan 掃描 RF 強度、Auto Scan 與 ACT 頻率同步快速配對四支麥克風。雙調諧器 True Diversity 純自動選訊,可拆式雙天線與天線串接座方便多台串接;四頻道各有 XLR 平衡與 6.3 mm 非平衡獨立輸出,另設混合輸出,音量 -10~+20 dB,並有 Lo-Cut/Flat 等化設定。

ACT-5814A 接收機特色

  • 全機架寬(19 吋)金屬機箱,後背板配置可拆式外接雙天線,並具天線輸出串接座,多台接收機可共用天線
  • MIPRO 獨家操作面板搭配高對比繪圖型 OLED 顯示器,畫面清晰、視角寬廣
  • ISM 5 GHz 頻段,有效避開 UHF、2.4 GHz 無線產品與 Wi-Fi 的干擾
  • 頻率規劃分 A、B 雙群組:A 群組 12 組頻道,B 群組再分 B1/B2 各 12 組,共 24 組頻道可選
  • 每頻道具 64 組 ID 及 1 組特殊 ID,同區多空間同時使用也不互相干擾
  • Channel Scan 頻道掃描偵測 RF 強度,Auto Scan 自動掃描 + ACT 頻率同步快速配對
  • 雙調諧器 True Diversity 純自動選訊接收,收訊穩定不中斷,B 群組傳輸延遲低於 1.5 ms
  • 48 kHz/24-bit 數位取樣,頻率響應 18 Hz~23 kHz、動態範圍逾 120 dBA,並具 Lo-Cut/Flat 等化設定
  • XLR 平衡與 6.3 mm 非平衡獨立輸出,另設 6.3 mm 混合輸出,音量調整範圍 -10~+20 dB,四頻道可獨立或混合輸出
  • 天線座提供強波器偏壓,可搭配 MIPRO 專業天線系統延伸接收距離
  • 可搭配 ACT-580 系列手握式與佩戴式發射器;外接 AC 100~240 V 交換式電源;台灣研發製造

ACT-580H 數位手握式無線麥克風 ×4

  • ISM 5.8 GHz 數位手握式發射器,頻寬 125 MHz,發射功率 20 mW,以 ACT 自動對頻與接收機同步
  • 霧黑色全金屬管身、超低手持雜音;電源模組整合開關與背光 LCD,顯示頻道、電量與 AF 音訊強度
  • 標配 MU-80A 心型電容式音頭,模組化設計可更換 MIPRO 各式電容或動圈式音頭,並支援他牌相容規格音頭
  • 電池座兩用專利設計:18500 鋰離子電池 ×1 或 AA 電池 ×2,可用 USB Type-C 或 MP-800/MP-820 充電座充電
  • 下管身可更換色環識別頻道,尾部專利天線保護蓋

套裝內容

  • ACT-5814A 5 GHz 數位四頻道接收機 ×1
  • ACT-580H 5 GHz 數位手握式發射器 ×4

適用場合

會議中心與企業多人會議、座談會與論壇、演講廳、多教室校園、教會與宗教聚會、Wi-Fi 密集的商業空間。只需要兩支麥克風可選 ACT-5812A 雙頻道系統;預算有限可選 2.4 GHz 的 ACT-2414A 四頻道系統。

相關產品

⚠ 頻段與相容性

ACT-5814A 為 5 GHz 數位系統,只能搭配 MIPRO 5 GHz 專用發射器(ACT-580H/ACT-580T 等 ACT-580 系列),無法與 UHF 或 2.4 GHz 發射器對頻;ACT-580H 可用 18500 鋰電池或 2 顆 AA 電池供電,充電需使用 USB Type-C 或 MP-800/MP-820 充電座。本站販售 MIPRO 台灣總經銷公司貨。

商品規格

頻道數
四頻道
機箱
全機架寬(19 吋)金屬機箱
頻段
ISM 5.8 GHz
頻寬
125 MHz
接收方式
純自動選訊
顯示螢幕
繪圖型 OLED 顯示器
操作介面
ACT 對頻按鍵、頻道選擇鍵與飛梭旋鈕
靈敏度
輸入 12 dBμV時,S/N > 100 dB
頻率響應
18 Hz ~ 23 kHz
動態範圍
> 120 dBA
傳輸延遲
< 1.5 ms(B 群組)
音訊 EQ
Lo-Cut / Flat 等化設定
展開完整規格(12 項)
音訊處理
48 kHz / 24-bit 數位取樣
音訊輸出
配置 XLR 平衡與 6.3 mm 非平衡獨立輸出,另設 6.3 mm 非平衡混合輸出,音量調整範圍 -10 ~ +20 dB
天線裝置
阻抗 50 Ω,TNC 天線座提供強波器偏壓,並具天線串接座
電源供應
DC 12 ~ 15 V,外接AC 100 ~ 240 V 交換式電源供應器
尺寸
420 × 44 × 162 mm (W×H×D)
重量
約 1.6 kg
發射器頻段
ISM 5.8 GHz
發射器頻寬
125 MHz
發射器發射功率
20 mW(依各國電波法規)
發射器音頭
標配 MU-80A 電容式音頭,可更換 MIPRO 或其他相容品牌音頭
發射器電源
18500 鋰離子電池 × 1 或 AA 電池 × 2,USB Type-C 或 MP-800/MP-820 充電座充電
發射器尺寸/重量
51 × 272 mm,約 320 g
