NT$ 5,490
Home » Modular Synthesizer » Mixer » Noise Engineering Nive Grad 立體聲電壓轉換器 Eurorack 模組
Nive Grad — 4HP 立體聲電平轉換器，讓吉他、效果器與 Eurorack 無縫整合
Nive Grad 是一款 4HP 的立體聲（或雙單聲道）電平轉換器（Level Shifter），讓你能輕鬆地將外部設備的訊號引入 Eurorack 系統，再把 Eurorack 的訊號送回外部設備——一個模組完成雙向轉換。無論是吉他、Bass、各種效果踏板，還是線路電平（Line Level）的合成器或錄音設備，Nive Grad 都能讓它們與你的 Eurorack 系統完美協作。
Nive Grad 的上半部為「升壓區」：接受外部低電平輸入，提供 +12 dB 與 +24 dB 兩種增益輸出，將訊號提升至 Eurorack 標準工作電平（約 10 Vpp），讓你的吉他或效果器訊號可以直接驅動 VCF、VCA、取樣機等任何 Eurorack 模組。下半部為「降壓區」：接受 Eurorack 電平輸入，提供 -12 dB 與 -24 dB 兩種衰減輸出，將訊號降低到踏板或線路設備所需的標準電壓，讓 Eurorack 的輸出能直接連接到吉他效果器鏈、錄音介面或喇叭系統。
Nive Grad 的輸入阻抗高達 1 MΩ，與被動式吉他（Passive Guitar）完全相容，不需要緩衝器即可直接接入。介面設計極為直觀，接線邏輯清晰，適合任何技術水準的 Eurorack 使用者。支援立體聲模式（兩路訊號同步升降）或雙單聲道模式（兩路訊號獨立使用），靈活性十足。
Nive Grad 特別設計成與 Noise Engineering 的 Xer Mixa 混音模組完美搭配，但同樣可以融入任何 Eurorack 系統或混音設置中。在僅 4 HP 的緊湊體積內，Nive Grad 是任何系統中整合外部設備的最佳解決方案。
產品特色
- 雙向電平轉換：外部設備信號升壓至 Eurorack 電平，Eurorack 訊號降壓至線路或踏板電平
- 上半部升壓區：提供 +12 dB 與 +24 dB 兩種增益輸出
- 下半部降壓區：提供 -12 dB 與 -24 dB 兩種衰減輸出
- 輸入阻抗 1 MΩ（高阻抗），相容被動式吉他直接接入
- 支援立體聲模式或雙單聲道（Dual-Mono）模式
- 介面簡潔直觀，接線邏輯清晰
- 與 Noise Engineering Xer Mixa 混音模組完美搭配
- 僅 4 HP，可融入任何規模的 Eurorack 系統
產品規格
- 類型：立體聲 / 雙單聲道電平轉換器（Level Shifter）
- 尺寸：4 HP
- 電源：+12V 25 mA、-12V 25 mA
- 輸入阻抗：1 MΩ（高阻抗，相容被動吉他）
- 升壓輸出：+12 dB、+24 dB（×2 組）
- 降壓輸出：-12 dB、-24 dB（×2 組）
- Nive — 拉丁語「niveum」即「水平、電平」之意；Grad — 拉丁語「步階、度數」之意
