NT$ 22,000
Home » Modular Synthesizer » VCO » INSTRUŌ Cš-L INSTRUO 模組化合成器
關於 INSTRUō
INSTRUō 是一家位於蘇格蘭格拉斯哥的模組化合成器公司，致力於發展高品質、創新的模組合成器。該品牌的產品範圍包括各種功能豐富的模組，從基本的振盪器到具有生物反饋功能的模組，各類型產品皆投入了不少創作心血。INSTRUō 的模組以其高品質、創新性而聞名，尤其是一些標誌性的產品，如 Scion 生物反饋至 CV 模組、Troika 三重振盪器和 Cs-Lcomplex 振盪器。時至今日 INSTRUō 仍不斷推出新產品，並為合成愛好者提供豐富的選擇，激發出他們獨一無二的音樂創作。
INSTRUō Cš-L
The Instruō Cš-L is a dual analogue oscillator optimised for generation of complex waveforms. It features two contrasting discrete circuit oscillators that are normalled to one another, offering a variety of simultaneous modulation routings. The resulting harmonic timbres sit far beyond the realms of traditional subtractive synthesis.
It expands upon the classic complex oscillator paradigm prominent in the West-coast synthesis philosophy. Typical cross modulation is expanded upon with inclusion of signal multiplication/amplitude modulation, a wavefolder per oscillator, final waveform symmetry biasing, classic and contemporary PWM, a global modulation index bus, and a digitally-controlled routing scheme that can be configured on-the-fly.
The two separate oscillator cores, simultaneous access to all included waveforms (both classic and contemporary), and the ability for bi-directional modulation, the Cš-L truly allows the user to shape sound like never before.
產品特色
- Sawtooth core voltage controlled oscillator (Oscillator A – Top)
- Waveforms: Sine, Triangle, Sawtooth, Pulse, wavefold final
- Triangle core voltage controlled oscillator (Oscillator B – Bottom)
- Waveforms: Sine, Triangle, Square/Sub, double pulse, wavefold final
- 1V/octave, Coarse and Fine pitch controls per oscillator
- Frequency modulation input per oscillator, linear or exponential response, with attenuators
- LFO range switch for oscillator A
- Switchable link between 1V/octave inputs for parallel tracking
- Multiply output with three modulator behaviour options
- CV over each wavefolder with attenuverters
- Symmetry offset control for each wavefolder with attenuverters
- CV controllable modulation bus (INDEX) with versatile definable internal routing
詳細規格
Size
-
26HP
-
Depth: 42mm
Power
-
+12V: 200mA
-
–12V: 80mA
