UNO is the first and only foldable case for eurorack modular synthesizers that folds patched. It is designed to ensure that your patch may easy “rest” when you’re traveling.

In a few seconds you can take it of from its soft padded bag, unfold it, power it and you’re done.

The patching system is compatible with the big part of standard eurorack cables, like Doepfer, AdInfinitum, Erica Synths, Black Market Modular, Befaco. It is also compatible with TipTop Audio’s Stackcables (up to 2 of them might be stacked per row, in the same area. Depending on the cables you’re using, it may be necessary to rotate the cables a bit to allow for the case to close perfectly and not to damage any jack socket.

Sizes

• 84HP – per row, for a total of 252HP
• 126HP – per row, for a total of 378HP

Woods Wenge, Zebra, Pear, Dark Zebra or the brand new Ovangkol

We specify that Dark Zebra is really rare: we had less than 7% on all the productions, and its request may lead to a long waiting list

Dimensions out of the bag (WxHxD in mm)

• folded: 470(84HP) / 684(126HP) x 210 x 297
• unfolded: 470(84HP) / 684(126HP) x 278 x 380

Max Depth Available

• 50 mm on upper and lower row
• up to 80 mm on inner row

SILTA powered

• 3’750 mA @ +12V, 1’250 mA per row
• 3’750 mA @ +12V, 1’250 mA per row
• 1’500 mA @ +5V on inner row

Included in each uno

• 1x UNO soft bag
• 1x SEI trunk lines module (mounted)
