Make Noise GTE Gestural Time Extractor 脈衝波萃取器模組

Name: Make Noise GTE Gestural Time Extractor 脈衝波萃取器 模組
Brand: Make Noise
Price: 6900 TWD
Availability: OutOfStock

Free shipping orders over NTD 3,000

NT$ 6,900

Earn 69 points with this purchase

Installment Info: (Details )

3 months 0 interest, per month NT$ 2,300

6 months 0 interest, per month NT$ 1,150

Type

Qty

Status: 預購商品 (約 10~15 個工作天)

Payment:

Free 1-year Warranty (except all cable, accessories and modulars) (Details)

Warranty Exclusions: Cables, power adapters and other accessories included in the box, Teenage Engineering Pocket Operator series, Modular synthesizers, Behringer HA400/MX400, MIDI Solutions series, microphone stands, hard cases, pedals and other accessories

This product has been viewed 4 times

NT$ 6,900

GTE - 8-Channel Gestural Pulse Extractor

Make Noise 專為 New Universal Synthesizer System 設計的類比脈衝萃取模組，從輸入的 CV 手勢動態中即時提取最多八個獨立閘道脈衝，同時輸出代表訊號移動速度的 GTE 脈衝流與奇偶聲道閘道。可搭配 Clock 輸入與系統其他事件同步，亦可作為 PoliMATHS 等模組的 Channel Index Translator 使用。

產品特色

動態萃取引擎

・從 Span 輸入端的 CV 動態中，萃取最多 8 個獨立聲道閘道脈衝

・GTE 輸出端持續輸出代表訊號移動速度的脈衝流

・Even 與 Odd 兩個閘道輸出，分別代表偶數與奇數聲道的活動狀態

靈活的同步與感度控制

・Space 參數決定各聲道的閾值間距，控制整體靈敏度與反應速度

・Clock 輸入接受 Trigger 或 Gate，使聲道切換與系統其他事件精準同步

Channel Index Translator 功能

・可作為 PoliMATHS 及其他 New Universal Synthesizer System 模組的 Channel Index 訊號轉換器使用

・與整個 Make Noise 複音生態系統無縫整合

詳細規格

連接

・CV 輸入：Span（聲道選擇，電壓越高聲道越高）

・Gate / Trigger 輸入：Clock

・閘道輸出：8 個獨立聲道脈衝輸出

・額外輸出：GTE 脈衝流、Even Gate、Odd Gate

電源

・+12V：25 mA

・-12V：2 mA

尺寸

・寬度：8 HP

・深度：29 mm（含電源連接線）
