INSTRUŌ øchd LFO INSTRUO 模組化合成器

Promo Price
NT$  6,900 NT$ 7,800
Earn 69 points with this purchase
Free shipping over NT$3,000
1-year warranty & repair
3/6-month 0% interest
Installment Info:
3 months 0 interest, per month NT$ 2,300
6 months 0 interest, per month NT$ 1,150
預購商品 (約 10~15 個工作天)
NT$ 6,900
øchd LFO INSTRUO 模組化合成器 INSTRUŌ øchd LFO INSTRUO 模組化合成器 NT$ 6,900

關於 INSTRUō

INSTRUō 是一家位於蘇格蘭格拉斯哥的模組化合成器公司,致力於發展高品質、創新的模組合成器。該品牌的產品範圍包括各種功能豐富的模組,從基本的振盪器到具有生物反饋功能的模組,各類型產品皆投入了不少創作心血。INSTRUō 的模組以其高品質、創新性而聞名,尤其是一些標誌性的產品,如 Scion 生物反饋至 CV 模組、Troika 三重振盪器和 Cs-Lcomplex 振盪器。時至今日 INSTRUō 仍不斷推出新產品,並為合成愛好者提供豐富的選擇,激發出他們獨一無二的音樂創作。

INSTRUō øchd

INSTRUō øchd 是一款 Modulation(調變)模組化合成器模組,在 4HP 的緊湊體積中容納 8 個全類比 LFO。

Designed in collaboration with Ben “DivKid” Wilson, the Instruō øchd packs 8 all analogue LFO’s into a convenient 4HP package. Each independent core is free running with rates configured from fastest to slowest arranged from top to bottom. Each frequency range was tuned by ear during development to give the optimum spread of control frequencies running in parallel. Being 100% analogue, the LFO’s will phase organically with the ability to ebb and flow together with their global frequency control.

Modulation breathes life into otherwise static patches, but CV sources can often run out quickly. Even in larger systems. øchd adds a lot of movement without hogging a lot of space. Both small lunch box cases and larger set ups can be made to drift, move and organically change over time. With either subtle use of øchd to keep things alive or wider ranging use that drives a whole patch that drifts around itself.

產品特色

  • 8 independent, un-synced free running analogue triangle LFO’s
  • Wide frequency range across the oscillators (160Hz to 25 minute cycle time, this goes much lower with CV)
  • CV controllable global rate with attenuverter
  • Track and Hold capabilities using negative CV to stall oscillator cores
  • Bipolar LED display for each LFO
  • Self patchable for complex wave shaping

官方介紹影片

商品規格

頻率範圍
160Hz 至 25 分鐘週期 (CV 可更低)
模組寬度
4HP
模組深度
32mm
+12V 電流消耗
80mA
–12V 電流消耗
80mA
LFO 數量
8 independent, un-synced free running analogue triangle LFO

Line 好友

保固說明

關於 DigiLog

加入好友

Reviews:

目前尚無評論

Purchase FAQ

Q1. How is shipping calculated? Is there free shipping?

Orders over NT$3,000 qualify for free shipping. Orders under NT$3,000 incur a NT$120 shipping fee. In-store pickup is always free.


Q2. What payment methods are available?

We accept: credit card (single payment, or 3/6-month installments), bank transfer, convenience store payment code, cash on delivery, in-store payment, and AFTEE deferred payment. Installments are currently available only for credit cards issued by CTBC Bank, E.SUN Bank, and Taishin Bank. Cash on delivery is not available for software products or orders over NT$10,000.

E-invoices are issued for all purchases and sent automatically to your registered email. Once a personal (duplicate) invoice is issued, it cannot be changed or reissued as a company (triplicate) invoice.


Q3. How does in-store pickup work?

Select "In-store pickup" (free) at checkout. We will notify you by email once your items are ready. Please bring your order information to the store.

Store address: 2F., No. 2-1, Aly. 2, Ln. 244, Sec. 3, Roosevelt Rd., Zhongzheng Dist., Taipei City. Opening hours: Monday to Saturday 11:00 – 18:30 (closed on Sundays).


Q4. What is the inspection period?

According to the Consumer Protection Act, online purchases come with a 7-day inspection period starting from the delivery date. Please note that the "inspection period is not a trial period." The purpose is for you to inspect and review the product, not to use it. If you are unsatisfied after inspection, please do not open or use the product and follow the return procedures immediately. Returned products must be in complete packaging with all accessories, gifts, and original packaging intact. Any missing, damaged, or incomplete items may affect your return rights and restoration costs may be deducted.


Q5. How do I process a return or exchange?

If you wish to return a product, please ensure it is in complete, new condition with the original packaging undamaged. This includes the product itself, accessories, warranty card, original packaging, and all accompanying documents. If the product is damaged due to reasons attributable to you, we may not be able to process the return, or repair costs may be deducted from the refund. However, products with manufacturing defects are exempt and qualify for unconditional return or exchange.

Please contact us by phone or email within the inspection period, providing the reason for the return/exchange, current product condition, phone number, and pickup address. We will arrange the return within 3-5 business days.


Q6. How will I receive my refund, and how long does it take?

Refund methods and timelines vary by payment method:

Credit Card: After we receive the returned product, the refund will be credited to your credit card account within approximately 5-7 business days. Depending on your billing cycle, the refund may appear on your current or next statement. Please confirm with your credit card issuing bank.

Bank Transfer: Please contact service [at] digilog.tw with your complete bank details (bank name, branch name, bank code, account holder name, account number). We will arrange courier pickup of the returned product and transfer the refund to your designated account within 5-7 business days.


Q7. Is there a warranty on products?

Products come with a 1-year warranty. For repairs during the warranty period, please contact service [at] digilog.tw or call +886-2-23638171.


Q8. Do I need to pay for shipping when sending products for repair?

Round-trip shipping costs for product repairs are the customer's responsibility.

INSTRUŌ Others:

INSTRUŌ tágh Modulation Source INSTRUO 模組化合成器 - Modulation
-8%
INSTRUŌ [1]f INSTRUO 模組化合成器 - Utility
-10%
INSTRUŌ cèis INSTRUO 模組化合成器 - Envelope
-9%
INSTRUŌ INSTRUO 模組化合成器 cuïr - In/Out
-10%
INSTRUŌ øchd Expander ochd 擴充板 INSTRUO 模組化合成器 - LFO
-8%

You may be interested in:

Make Noise MATHS Multifunctional 多功能模組 - Modulation
-3%
4ms Stereo Triggered Sampler (STS) 模組化合成器 - Sampler
-7%
Noise Engineering Ataraxic Iteritas Alia - VCO
-7%
VCO

Noise Engineering Ataraxic Iteritas...

NT 14,200 Price NT 13,200
Erica Synths Pico VCO2 - VCO
