Polyend Poly | DigiLog 聲響實驗室
買器材 » 模組化合成器 » MIDI to CV » Polyend Poly
Poly

Polyend Poly

滿 NT$ 5,000 全亞洲區免運費

促銷價 NT$ 16,500

分期資訊:
30 利率,每期 NT$ 5,500
60 利率,每期 NT$ 2,750

商品狀態:預購商品 (約 10~15 個工作天)

保固資訊:1 年保固 (不包含: 配件、線材、modular)
滿 NT$ 5,000 全亞洲區免運費
付款方式: 7 11 Family mart Hilife Ok Visa Jcb Atm Cash delivery

MIDI connected to modular world

There are many great, functional MIDI tools and devices (DAWs, controllers, sequencers, keyboards etc.) and as many fantastic Eurorack modules. Poly seamlessly connects these worlds thanks to its multiple inputs and outputs.



The interface

Poly equips you with all kinds of MIDI inputs. Connect your computer, smartphone or tablet to its USB port, your class compliant MIDI controllers via USB Host, and all the other devices via the classic MIDI DIN port. A whole array of analog outputs give you the versatility to hook up loads of different types of modules. Eight rows of Gate, Pitch, Velocity, and Modulation let you freely control synth and drum voices.



MPE compatible

We are huge fans of MIDI and its vast possibilities. That's why we created Poly to be compatible with MPE standard (Multidimensional Polyphonic Expression). We believe that MPE is a perfect match for the modulars.



Three modes, totally different possibilities

Depending on what you want to achieve, there are three modes you can choose from: First, Next and Channel. Both First and Next modes are perfect for building your unique polyphonic synthesizer. In Channel mode a DIP switch on the back panel lets you choose between MIDI channels 1-8 or Notes C-G that are directed to corresponding CV voices.



Poly Tutorial by Once upon a synth

The Poly allows you to use your digital gear like a DAW, drum machine, keyboard, iPhone, etc to control your eurorack modules. The "polyphonic" part means that you can play chords and assign each note of the chord to a different oscillator for example. There are 8 different channels, each with gate, pitch, velocity and modulation jacks.



I/O

Input:
MIDI DIN
USB A (5V)
USB B

Output:
8x Gate (0-12V)
8x Pitch (0-12V, V/oct)
8x Velocity (0-12V)
8x Modulation (0-12V, selectable CC message 0-127 using DIP switch on the back panel)
