Tiptop Audio Z8000 New Version

Z8000 — Matrix Sequencer / Programmer

Tiptop Audio Z8000 是一款 Eurorack 矩陣序列器（Matrix Sequencer / Programmer），以 16 顆旋鈕為核心，可同時被十組各自獨立的序列器存取運用。

關於 Z8000

The Z8000 Matrix Sequencer is a modulation source like no other: The 16 knobs of the Z8000 are accessed by ten sequencers with their own clock, direction and reset inputs. The ten sequencers are as follows:

• Four 4 step CV sequencers on the horizontal.
• Four 4 step CV sequencers on the vertical.
• One 16 step CV sequencer on the horizontal.
• One 16 step CV sequencer on the vertical.

The Z8000 can simultaneously modulate up to 10 CV parameters poly-rhythmically, with unprecedented motion complexity. One knob affects all 10 CV outputs! Imagine modifying 10 parameters from one knob. With its 30 gate and clock inputs and 10 CV outputs one can only imagine the possibilities, and all clock inputs can even be driven at audio rates! The Z8000 pairs well with the Trigger Riot and Circadian Rhythms and using it with the QuantiZer extends its capabilities as a high-precision 1V/Oct note sequencer.

Introduced in 2017, a new version of the Z8000 maintains the original circuitry but adds output range adjustment switches on the back and Tiptop’s new colored look, which helps highlight the sections, on the front.

Z8000 sequencer controls, Z3000 pitch and one sequencer controls, Z2040 cut off.
