復刻經典，再造風潮 - Buchla X Tiptop Audio

歡迎來到 Buchla & Tiptop Audio 200 系列。
在這個系列中， Buchla 與 Tiptop Audio 聯手復刻了 Don Buchla 的 200 系列，並使之成為 Eurorack Format ，讓這些半個世紀前製造的、極為罕見的設備再次為世人所見。
每個模組皆限量製造，將根據生產計劃和零部件供應情況進行獨立生產，可說是相當稀有。

TIPTOP AUDIO BUCHLA 207T

The Tiptop 207t is a modern reimagining of the classic Don Buchla 207 Mixer/Preamplifier from the 1970s 200 Series. This stereo mixer comes with a built-in preamp that allows you to boost external instruments and microphones, making it a versatile tool for any modular setup. The 207t also features a six-channel mixer with a variety of signal routing options, including the ability to route channels to the monitor and L&R signal outputs, with per-channel control over loudness and panning.

Each channel has a Mon switch that sends the channel's signal to the monitor outputs, which are always full-volume and summed to mono, making it useful for basic monitoring applications or rudimentary mixing. The Prog switch sends the signal to the L&R signal outputs, with loudness controlled by the Level Adjustment slider and panning determined by the Channel Assignment knobs. The first and sixth channels offer voltage control of panning; these channels are hard-panned when no CV is applied.

The preamp section features a 1/4" input and multiple gain settings, making it suitable for use with external line level instruments, electric guitars, or dynamic microphones. The continuous amplification control provides added flexibility for your audio needs. Finally, the Expansion In is a stereo input that sums to the left and right main outputs, which is great for chaining multiple 207t modules or adding another stereo source at the final output.

While the 207t's functionality may be simple, it is an essential part of any 200t system, serving as the glue that holds everything together. The Tiptop 207t is a fantastic mixer/preamp option that delivers quality sound and reliable performance.

產品特色

• Mixer/preamp module based on Don Buchla's original 207 design
• Six-channel mixer with per-channel level control and panning
• Voltage-controllable panning on channels 1 and 6
• Manual panning on channels 2–4
• Program switches can act as channel mutes for main outputs
• Mon switches route signal (in mono) to Monitor output
• Expansion input useful for stereo chaining and more
• Re-designed preamp for high audio fidelity
• Preamp suitable for use with external instruments, electric guitars, dynamic microphones, and more

詳細規格

• Eurorack 標準 3U 規格
• Width: 28hp
